The BERNINA 580 Liberty Edition celebrates a romantic fusion of two visionary heritage brands whose creative worlds naturally intertwine. Produced in a limited edition, the B 580 Liberty Edition features an exclusive faceplate printed in Liberty’s Glen Lyon Blooms print – an ode to timeless artworks carefully redrawn and hand painted in the Liberty design studio in the heart of London.

• Faceplate in Glen Lyon Blooms design by Liberty
• Matching Liberty dust cover
• Embroidery Module M (SDT) included
• Exclusive 32 Liberty decorative stitches
• Matching Liberty Trolley set

Specifications
General Information

Special edition model in a limited number
Faceplate printed in exclusive Liberty print
BERNINA Hook system
Maximum sewing speed (stitches per minute) - 1,000
Space to the right of the needle - 8.5 inches
Color touch screen - 4.3 inches
LED sewing lights - 12 LEDs
Multi-function knobs
Maximum stitch width - 9 mm
Maximum stitch length - 6 mm
Needle positions - 11
Sewing in every needle position
Number of spool holders - 2
Semi-automatic needle threader
Automatic presser foot lift
Automatic presser foot pressure
Automatic thread cutter
Pivot / Hover function
Manual thread cutters - 4
BERNINA Dual Feed (BDF)
BERNINA Adaptive Thread Tension
BERNINA Stitch Regulator (BSR) functionality
Start / stop button
Slide speed control
Upper thread sensor
Lower thread sensor
USB interface for PC connection
BERNINA foot control with needle up / down function
Needle stop up / down
Drag & Drop
Bobbin winding while sewing / embroidering
On-screen help
Setup program
Sewing and Quilting

Pattern start / end function
Triple Stitch
Elongation
Programmable securing function
Pattern end programmable
Total number of stitch patterns (incl. alphabet) - 1482
Memory (short-term / altered stitches)
Memory (long-term / altered stitches)
Create and save stitch combinations
Changing stitch settings while sewing
Exclusive Liberty decorative stitches - 32
Utility stitches total - 35
Buttonholes (incl. eyelets) total 1- 6
Automatic buttonhole length measuring system
Automatic buttonhole
Manual multi-step buttonhole
Button sew-on program
Darning programs
Decorative stitches total - 482
Quilting stitches total - 74
Sewing alphabets - 8
Sewing tutorial
Creative Sewing Consultant
Embroidery

Embroidery functionality
Embroidery Module M with Smart Drive Technology (SDT)
Maximum embroidery field - 400x150mm (15.7“x5.9“)
Maximum embroidery speed (stitches per minute) - 1,000
Built-in embroidery designs - 349
Exclusive Liberty embroidery designs - 91
Embroidery alphabets - 7
Read Embroidery Design Formats: EXP, DST, PES, PEC, JEF, SEW, PCS, XXX
On-Screen Design editing: positioning, mirroring, rotating, scaling, combining
Invisible Secure
Smart Secure
Thread-up Command
Programmable jump stitch cutting
Thread Away Mode
WordART
Freearm embroidery
Color resequence
Sequence control
Embroidery Tutorial
Import/ Export of designs via USB
Small Clamp Hoop functionality, embroidery field: 6.25“×6.5“ (158×165 mm)
Large Freearm Hoop functionality embroidery field: 5.7“×10“ (145×255 mm)
Midi Hoop functionality, embroidery field 10.4"×6.5" (265×165 mm)
Mega Hoop functionality, embroidery field 15.7"×5.9" (400×150 mm)
Personal memory for embroidery designs
Basting
Position recall
