Features
Large Work Surface: The generous 12 wide throat space allows you to finish big projects with ease.
Custom Switches: Two easily accessible switches (A and B) can be assigned for operations, for example, needle up and down or raising the presser foot.
Independent Bobbin Winder: The QVPs bobbin winder operates with an independent motor. Full capacity L size bobbins filled with your favorite thread ready to complete your project.
One-Touch Switching to Free Motion Mode: The machine is equipped with a button for switching between straight stitch mode and free motion mode.
Micro-Lifter Function: By inputting a negative value for the presser foot pressure, fabric can be sewn with the presser foot floating at a height of 0 to 4mm. This helps when sewing thick seams and reduces uneven feeding when quilting.
Digitally Controlled LCD Panel: Adjust settings, for example, stitch length, thread tension, presser foot pressure with the touch of a button. Settings can be confirmed and specified from this large panel.
Bobbin Thread Counter: With the count changing by one for every 10 stitches sewn, the counter can be used as a guide for when to replace the bobbin thread.
Four Feed Operation Types: From the operation panel, you can select the appropriate feed operation for the item being sewn: standard for normal fabric, front up for thin fabric or knits, rear up for thick fabrics, and box feed for quilting.
Adjustable LED Light: using an easily accessible switch, the brightness can be adjusted to one of five levels.
Easily Insert and Remove Thick Fabrics: When the presser foot is raised, the feed dog is automatically lowered. In addition, the presser foot can be raised to a height of up to 13.5mm allowing thick fabrics to easily be inserted and removed.
Maintenance-Free: Fill oil tank through the filler opening at the front of the sewing machine to ensure that the hook is automatically lubricated
Specifications
Sewing Speed: Max. 2,500 spm
Max. Stitch Length: 5mm
Needle: DBx1 #9-#18
Bobbin: "L" style
Working Area: 5.5 w x 12 h
Machine Weight: 26 kg (57lbs)
Main Table: 48 w x 22 h
Extension: 48 w x 20 h
Total Work Area: 48 x 42 h
Accessories
Included Accessories:
Standard Presser Foot
Presser Foot
Quilting Foot (for Ruler)
Bobbins (4pcs)
Needles
Thread Stand Components
Thread Stand Bracket
Thread Guide Pin
Small Screwdriver
Medium Screwdriver
Hexagonal Wrench
Cleaning Brush
Spool Cap
Sewing Machine Cover
Oiler
Optional Accessories:
Hinged Zipper Foot (Part No. A9842D250A0)
Invisible Zipper Foot (Part No. A9841D25AA0)
Smooth Foot (Part No. A9840D250A0)
Compensating Foot, Right 1.5mm (Part No. A9843D25AA0)
Regular Hinged Foot (Part No. 4017126)
Glide Foot, (Part No. 40201924)
Couching Foot, (Part No. 40148899)
